第一步,安装cert-manager:
https://cert-manager.io/docs/installation/kubernetes/
第二步,安装自签名ClusterIssuer(所有Namespace共用):
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
name: FooBarSelfSign
spec:
selfSigned: {}
第三步,签发CA证书(Application Namespace自用):
apiVersion: cert-manager.io/v1alpha2
kind: Certificate
metadata:
name: FooBarCACertificate
spec:
secretName: FooBarCACertificate
isCA: true
issuerRef:
name: FooBarSelfSign
kind: ClusterIssuer
commonName: "FooBar CA"
第四步,安装CA(Application Namespace自用):
apiVersion: cert-manager.io/v1alpha2
kind: Issuer
metadata:
name: FooBarCA
spec:
ca:
secretName: FooBarCACertificate
第五步,生成随机JKS密码(Application Namespace自用):
NOTE:如果不需要JKS可以省略这步。
apiVersion: v1
kind: Secret
metadata:
name: FooBarJKSPassword
data:
Password: {{ uuidv4 | b64enc }}
第六步,使用CA签发Application证书(Application Namespace自用):
NOTE:如果不需要JKS,可以省略keystores
的部分
---
apiVersion: cert-manager.io/v1alpha2
kind: Certificate
metadata:
name: FooBarServerCertificate
spec:
secretName: FooBarServerCertificate
duration: 2160h # 90d
renewBefore: 360h # 15d
keySize: 2048
keyAlgorithm: rsa
keyEncoding: pkcs1
commonName: server.foobar.com
keystores:
jks:
create: true
passwordSecretRef:
name: FooBarJKSPassword
key: Password
issuerRef:
name: FooBarCA
kind: Issuer
group: cert-manager.io
---
apiVersion: cert-manager.io/v1alpha2
kind: Certificate
metadata:
name: FooBarClientCertificate
spec:
secretName: FooBarClientCertificate
duration: 2160h # 90d
renewBefore: 360h # 15d
keySize: 2048
keyAlgorithm: rsa
keyEncoding: pkcs1
commonName: "FooBar Client"
keystores:
jks:
create: true
passwordSecretRef:
name: FooBarJKSPassword
key: Password
issuerRef:
name: FooBarCA
kind: Issuer
group: cert-manager.io
生成的FooBarServerCertificate
和 FooBarClientCertificate
包含以下内容:
- tls.key – 证书私钥
- tls.crt – 证书
- ca.crt – CA证书
- keystore.jks
- truststore.jks
第七步,安装签发的证书到应用:
示例1 – Server Deployment:
apiVersion: apps/v1
kind: Deployment
metadata:
name: FooBarServer
spec:
template:
spec:
containers:
- name: FooBarServer
volumeMounts:
- name: tls
mountPath: /var/ssl/private
readOnly: true
volumes:
- name: tls
secret:
secretName: FooBarServerCertificate
items:
- key: truststore.jks
path: foobar-truststore.jks
- key: keystore.jks
path: foobar-keystore.jks
...
示例2 – Ingress Client:
apiVersion: networking.k8s.io/v1beta1
kind: Ingress
metadata:
name: FooBarIngress
annotations:
kubernetes.io/ingress.class: nginx
# enable mTLS for frontend
nginx.ingress.kubernetes.io/auth-tls-verify-client: "on"
nginx.ingress.kubernetes.io/auth-tls-verify-depth: 2
nginx.ingress.kubernetes.io/auth-tls-pass-certificate-to-upstream: "false"
# read the ca.crt part of the certificate
nginx.ingress.kubernetes.io/auth-tls-secret: <another certificate for frontend>
# enable mTLS for backend
nginx.ingress.kubernetes.io/proxy-ssl-verify: "on"
nginx.ingress.kubernetes.io/proxy-ssl-secret: FooBarClientCertificate
spec:
rules:
- host: server.foobar.com
http:
paths:
- path: /xxx
backend:
serviceName: FooBarAppService
servicePort: xxx
tls:
- hosts:
- server.foobar.com
# read the tls.key and tls.crt parts of the certificate
secretName: <another certificate for frontend>
...
